Specifikace
Jméno značky | VŠE V JEDNOM |
Modelka | AIN7260 |
Záruka | 5 let |
Jmenovité napětí | 76.8V |
Jmenovitá kapacita | [email protected]/customize |
Energie | 4416Wh |
Vnitřní odpor | ≤ 50 mΩ |
Život v cyklu | 4000 Cycles @ 0.2C Charging/Discharging ,Until 80% Capacity |
Vlastní výboj | ≤3,5% za měsíc při 25 ℃ |
Max. Nabíjecí napětí | 87.6 V |
Režim nabíjení | At 0℃~45℃ temperature, charged to 87.6 V at a constant current of 0.2C, and then,changed continuously with constant voltage of 87.6 V until the current was not more than 0.02C |
Nabíjecí proud | 30A |
Max. Nabíjecí proud | 60A |
Vybíjecí proud | 30A |
Max. discharge Continuous Current | 60A |
Max. Pulzní proud | 120A(<3S) |
Vybíjení cut-off napětí | 60V |
Teplota nabíjení | 0 ℃ až 45 ℃ (32 ℉ až 113 ℉) při 60 ± 25% relativní vlhkosti |
Vypouštěcí teplota | -20 ℃ až 60 ℃ (-4 ℉ až 140 ℉) při 60 ± 25% relativní vlhkosti |
Skladovací teplota | 0 ℃ až 45 ℃ (32 ℉ až 113 ℉) při 60 ± 25% relativní vlhkosti |
Odolnost proti vodnímu prachu | IP55 |
Buňka a formát | LFP 60AH 24S1P/customize |
Kryt | Metal Case |
Rozměr (L * W * H * TH) | přizpůsobit |
Hmotnost | 50kg |
Terminál | M6 or Anderson or another bolt screw |
Peak discharge current BMS | 60A |
High temp port. Low temp port. | over charge port. over discharge port. |
Metoda nabíjení | CC / CV |
Terminal Type | M6 or Anderson or another bolt screw/customize |
Osvědčení | CE, RoHS ,MSDS and UN38.3 certification |
applications | Golf Carts, Electric Forklifts,Slow Speed Car; AGV,Electric Motorcycle; Sightseeing car;RV ,Tricycle, electric vehicles, Electric Wheelchairs, Electric Power Systems, Uninterruptible Power Supplies, Solar Energy Storage Systems,BOATS |
Připomínka
1.Support customization, according to the specifications required by customers: voltage, capacity, power, working current, size,weight.
2. Factory wholesale price, our factory has a price advantage. Cells of the same level are the cheapest, and you can choose the corresponding cells to make a battery pack according to your requirements.
3.Before placing Order please contact customer service to communicate the required specifications to confirm the price.
aplikace
Naše továrna
Why to choose us?
* We have our own factory and company, which belong to an absolute integration of industry and trade.
* A large number of batteries are in stock.
* Have very good product resources.
* Good product quality and favorable price.
* The product is 100% original and brand new.
* 100% on time delivery. Fast delivery.(including battery pack <7 days).
* Long warranty 2-5 years.
* provide sample 2-7 days.
* Professional after-sales service.
* We have a complete industrial chain and professional engineers can make battery packs that satisfy you as quickly as
possible.
If you want to know more about the information, please free feel to contact me. Thanks!
Balení a doprava
Balení
1). Carton Size: customized or based on actual weight and volume, best quality.
2). 5-layers exporting carton or customized outer packaging for paper bags;
Lodní doprava
1). By Express (3-30working days),there are express shipping or economic shipping,suitable for small quantity.
2). By Train(25-28days),for EU Country,including customs clearance, all the import tax fees and UPS delivery to the door.
3). By Sea (15-30 days), it suitable for regular mass production.
We cooperate with excellent international freight forwarding companies to provide cheap and efficient logistics services. If you have any shipping issues, please feel free to contact me.
FAQ
Otázka: Jak mám platit? Jaké způsoby platby přijímáte?
A: T/T, PayPal, Western Union.
Otázka: Je vzorová objednávka přijatelná?
Odpověď: Ano, pro většinu baterií jsou vzorové objednávky pro testování kvality rozumné a přijatelné.
Q: Is your battery quality approved?
A: Yes, we guarantee that all cells are 100% original from Brand. And we will have full inspection of each cells and grouping them before assembling into battery packs. And all finished battery packs will be under a full inspection
before shipment.
Q: How can you prove that your cells are 100% original?
A: We can show you the original pack list and other related documents.
Q: what is your lead time if I placed an order?
A: For all products in stock, our lead time is within 2 working days after payment received. For these that we don't stock for the moment such as customized battery packs, the lead time is around 7-10 days.
Q: What is your warranty?
A: These situations not provide return nor refund:
1.After the assembly or assembly process happen any problem, such as the protection board connected to the wrong wire burned lead to battery damage, charger failure, the assembly error or unbalanced assembly, etc.
2. V případě poškození, jako je vyboulení/svaření baterie, baterie bez ochrany BMS způsobená nabíjením.
